Tesla Model 3 Left Front Brake Caliper 8008202-00-A 2017-2023

Basic Informationteslacarparts.eu

• Part Number: 8008202-00-A
• Product Name: Front Brake Caliper Without Pads - Left Hand - Base
• Applicable Model: Tesla Model 3 (2017 - 2023)
• Features: It is a left - hand front brake caliper of the base version, without brake pads included.

Function and Importance

Installation and Related ConsiderationsTesla

• Installation Torque: When installing this brake caliper, specific torque values need to be followed. For example, the bolts fixing the left - front brake caliper to the left - front steering knuckle require a torque of 94 Nm (69.3 lbs - ft), and the bolts fixing the left - front brake hose to the left - front brake caliper need a torque of 42 Nm (31.0 lbs - ft).
• Installation Steps: First, remove the old brake caliper from the vehicle, clean the relevant parts, then install the new 8008202-00-A brake caliper in place, connect the brake hose and other components, and finally perform a brake bleeding procedure to ensure the normal operation of the braking system. It is recommended to have professionals install it to ensure installation quality and safety.

Product Advantage

• Original - Equipment Quality: This brake caliper is designed and manufactured in accordance with Tesla's original - equipment standards, ensuring compatibility and reliability with Model 3 vehicles. It has the same quality and performance as the original parts, which can meet the high - quality requirements of Tesla owners for vehicle components.
• Lightweight Design: Similar to other Tesla brake calipers, it may adopt an integrated casting technology with built - in oil circuits. The overall weight, including the brake pads, is 4.4 kg, which has a very high - level lightweight design. Reducing the unsprung weight can significantly improve the vehicle's dynamic performance, braking response speed, and at the same time, have a positive impact on the vehicle's handling, power, and range.
