Bracket, Rear Bumper Upper Center, LH for Tesla Model S (2021-) | 1613990-00-A (CFN Brand)

1. Basic Information

2. Core Selling Points

• OEM-Precise Fit: Precision-stamped to match Tesla’s original bracket dimensions (length: 145mm ±1mm, width: 40mm ±0.5mm, thickness: 3mm) and mounting hole positions. Directly aligns with factory bolt points on the rear frame and rear bumper—no drilling, bending, or trimming required for a tight, stable connection.
• Long-Lasting Anti-Corrosion: Galvanized steel base + electrophoretic coating resists road salt, rain, and humidity. Passes 720-hour salt spray tests (ASTM B117) without rust or coating peeling, ideal for use in coastal, snowy, or high-humidity regions.
• Reinforced Stress Resistance: Triangular rib structure at key stress points enhances load-bearing capacity (supports up to 40kg, matching OEM standards). Prevents the rear bumper’s upper center section from sagging under its own weight or during bumper removal/installation.
• Tool-Simple Installation: Pre-drilled M6-compatible mounting holes align with Tesla’s factory hardware. Install with a 10mm socket—position the bracket, tighten bolts to 9±1 Nm torque, and verify bumper alignment post-installation (no specialized tools needed).

3. Key Specs & Installation Tips

• Key Specifications: Material: Galvanized steel + electrophoretic coating; Dimensions: 145mm (length) × 40mm (width) × 3mm (thickness); Tensile strength: ≥350MPa; Temperature resistance: -40°C to 120°C; Service life: ≥10 years (under normal use).
• Installation Tips: 1. Open the rear trunk, use a trim tool to remove the inner trim panel (avoid scratches) and access the rear bumper upper mounting area; 2. Remove the old LH bracket by detaching 3 factory bolts (10mm socket); 3. Clean the frame’s mounting surface to remove rust or debris; 4. Align the CFN LH bracket with bolt points, tighten bolts to 9±1 Nm; 5. Reinstall the inner trim panel and check that the rear bumper sits flush with the body.
• Critical Note: This is an LH (Left-Hand) exclusive bracket—confirm your Model S’s production year (2021+) and side configuration (driver/passenger side per region) before purchase; pre-2021 Model S uses a non-compatible bracket design.

4. After-Sales & Bulk Support

• Warranty: 4-year warranty (covers manufacturing defects such as rust, bending, or misaligned holes; excludes damage from collisions, over-tightening bolts, or improper handling).
• Bulk Offers: Orders of ≥15 pieces enjoy 15% discount; bulk buyers (e.g., repair chains) receive free anti-rust maintenance guides and flexible delivery schedules.
• Maintenance Tip: Inspect annually for loose bolts or rust spots—tighten bolts promptly if loose, clean with a dry cloth to remove salt/debris, and avoid abrasive cleaners that damage the anti-corrosion coating.
