Bracket, Rear Bumper Upper Center, RH for Tesla Model S (2021-) | 1613991-00-A (CFN Brand)

1. Basic Information

2. Core Selling Points

• OEM-Grade Fit & Rigidity: Precision-stamped to match Tesla’s original bracket dimensions (length: 145mm ±1mm, width: 40mm ±0.5mm, thickness: 3mm) and mounting hole positions. Directly aligns with factory bolt points on the rear frame and rear bumper—no drilling or bending required, ensuring a tight, stable connection.
• Anti-Corrosion Durability: Galvanized steel base + electrophoretic coating resists road salt, rain, and humidity. Passes 720-hour salt spray tests (ASTM B117) without rust or coating peeling, suitable for long-term use in coastal or snowy regions.
• Stress Distribution Design: Reinforced triangular rib structure at key stress points enhances load-bearing capacity (supports up to 40kg, matching OEM standards). Prevents the rear bumper’s upper center section from sagging under its own weight or during bumper removal/installation.
• Easy Installation: Pre-drilled mounting holes (3 holes, M6 bolt compatible) align with Tesla’s factory hardware. Can be installed with a 10mm socket—simply position the bracket, secure bolts to 9±1 Nm torque, and verify bumper alignment post-installation.

3. Key Specs & Installation Tips

• Key Specifications: Material: Galvanized steel + electrophoretic coating; Dimensions: 145mm (length) × 40mm (width) × 3mm (thickness); Tensile strength: ≥350MPa; Temperature resistance: -40°C to 120°C; Service life: ≥10 years (under normal use).
• Installation Tips: 1. Open the rear trunk and remove the inner trim panel (use a trim tool to avoid scratches) to access the rear bumper upper mounting area; 2. Remove the old bracket by detaching 3 factory bolts (10mm socket); 3. Clean the frame’s mounting surface to remove rust/debris; 4. Align the CFN RH bracket with the bolt points, tighten bolts to 9±1 Nm; 5. Reinstall the inner trim panel and check if the rear bumper sits flush with the body.
• Note: This is a RH (Right-Hand) specific bracket—confirm your vehicle’s side configuration (driver/passenger side) and Model S production year (2021+) before purchase; pre-2021 Model S uses a different bracket design.

4. After-Sales & Bulk Support

• Warranty: 4-year warranty (covers manufacturing defects such as rust, bending, or misaligned holes; excludes damage from collisions, over-tightening bolts, or improper handling).
• Bulk Offers: Orders of ≥15 pieces enjoy 15% discount; bulk buyers (e.g., repair chains) receive free anti-rust maintenance tips and flexible delivery schedules.
• Maintenance Tip: Inspect the bracket annually for loose bolts or rust spots—tighten bolts promptly if loose, and clean with a dry cloth to remove salt/debris; avoid using abrasive cleaners that damage the anti-corrosion coating.
