Bracket, Rear Bumper Lower Center, LH for Tesla Model S (2021-) | 1614074-00-A (CFN Brand)

1. Basic Information

2. Core Selling Points

• OEM-Level Fit Precision: Precision-stamped using Tesla’s original design data, with dimensions (length: 130mm ±1mm, width: 35mm ±0.5mm, thickness: 3.5mm) and mounting hole positions identical to factory parts. Directly aligns with the rear subframe and rear bumper’s factory bolt holes—no drilling, bending, or trimming required, ensuring a tight and stable connection.
• Superior Anti-Corrosion Performance: Galvanized steel base forms a primary anti-rust barrier, and the black electrophoretic coating adds a secondary protective layer. Passes 800-hour salt spray tests (per ASTM B117) without rust, peeling, or discoloration, suitable for long-term use in coastal, snowy, or high-humidity areas.
• Reinforced Load-Bearing Capacity: Equipped with a cross-ribbed structure at stress points (e.g., bumper attachment areas), the bracket supports up to 45kg (matching OEM standards). Effectively resists the rear bumper’s weight and impact from road debris, preventing the lower bumper from sagging or deforming during daily driving.
• Effortless Installation: Pre-drilled M6-compatible mounting holes align with Tesla’s factory hardware. Can be installed with a standard 10mm socket—simply position the bracket, tighten the bolts to 10±1 Nm (per Tesla’s factory torque specs), and complete the installation in 15–20 minutes (no specialized tools needed).

3. Key Specs & Installation Tips

• Key Specifications: Material: Galvanized steel + electrophoretic coating; Dimensions: 130mm (length) × 35mm (width) × 3.5mm (thickness); Tensile strength: ≥380MPa; Temperature resistance: -40°C to 130°C; Service life: ≥10 years (under normal use).
• Installation Tips: 1. Lift the vehicle and secure it with jack stands (focus on rear subframe support points); 2. Remove the rear underbody splash guard (use a trim tool to avoid scratches) to access the lower bumper mounting area; 3. Detach the 3 factory bolts (10mm socket) to remove the old LH bracket; 4. Clean the subframe’s mounting surface to remove rust or debris; 5. Align the CFN LH bracket with the bolt holes, tighten the bolts to 10±1 Nm; 6. Reinstall the splash guard, lower the vehicle, and check if the rear bumper’s lower section sits flush with the body.
• Critical Compatibility Note: Exclusive to 2021+ Tesla Model S; pre-2021 Model S has a revised rear bumper and subframe design—confirm your vehicle’s production year before purchase. Do not mix with RH (Right-Hand) brackets (part number 1614075-00-A) as they are side-specific.

4. After-Sales & Bulk Support

• Warranty: 4-year warranty (covers manufacturing defects such as rust, bending, or misaligned mounting holes; excludes damage from collisions, over-tightening bolts, or off-road use).
• Bulk Offers: Orders of ≥20 pieces enjoy 18% discount; bulk buyers (e.g., repair chains) receive free technical support (installation video guides, torque verification tips) and customized delivery schedules.
• Maintenance Tip: Inspect the bracket every 6 months for loose bolts or rust spots—tighten bolts promptly if loose; clean the bracket with a dry cloth to remove road salt or debris (avoid abrasive cleaners that damage the anti-corrosion coating).
